Parent Layer: Storm Sewer

Name: Storm Channels

Display Field: FACILITYID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Linear feature of drainageways can be natural or artificial channels for stormwater, depending on the location and geography. This layer includes the larger natural creeks and streams as tributaries in the South Platte River watershed.

Service Item Id: 8a110ac22f8043cc89c4389fa1461b59

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.170086902610401E7
YMin: 4799045.83746365
XMax: -1.168374889320183E7
YMax: 4814142.529972504
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 255, 197, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FACILITYID ( type: esriFieldTypeString, alias: Facility Identifier, length: 20 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• TOPWIDTH ( type: esriFieldTypeDouble, alias: Top Width )
• BOTWIDTH ( type: esriFieldTypeDouble, alias: Bottom Width )
• DEPTH ( type: esriFieldTypeDouble, alias: Depth )
• BEDMATERIAL ( type: esriFieldTypeString, alias: Bed Material, length: 50 , Coded Values: [ABS: ABS Plastic] , [AC: Asbestos Cement] , [ASP: Asphalt] , ...35 more... )
• SIDEMATERIAL ( type: esriFieldTypeString, alias: Side Material, length: 50 , Coded Values: [ABS: ABS Plastic] , [AC: Asbestos Cement] , [ASP: Asphalt] , ...35 more... )
• LEFTSLOPE ( type: esriFieldTypeDouble, alias: Left Slope )
• RIGHTSLOPE ( type: esriFieldTypeDouble, alias: Right Slope )
• UPTOP ( type: esriFieldTypeDouble, alias: Uptop )
• DWNTOP ( type: esriFieldTypeDouble, alias: Down Top )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• ACTIVEFLAG ( type: esriFieldTypeSmallInteger, alias: Active Flag , Coded Values: [0: False] , [1: True] )
• OWNEDBY ( type: esriFieldTypeSmallInteger, alias: Owned By , Coded Values: [4: Centennial Downs Metropolitan District] , [5: Cherry Hills Heights] , [6: Cherry Hills Village] , ...28 more... )
• MAINTBY ( type: esriFieldTypeSmallInteger, alias: Managed By , Coded Values: [4: Centennial Downs Metropolitan District] , [5: Cherry Hills Heights] , [6: Cherry Hills Village] , ...28 more... )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHEETREF ( type: esriFieldTypeString, alias: SHEETREF, length: 50 )
• LOCDESC ( type: esriFieldTypeString, alias: Location Description, length: 200 )
• GPSDATE ( type: esriFieldTypeDate, alias: GPS Date, length: 8 )
• UPELEV ( type: esriFieldTypeDouble, alias: Upstream Elevation )
• DOWNELEV ( type: esriFieldTypeDouble, alias: Downstream Elevation )
• TOMH ( type: esriFieldTypeString, alias: To Feature, length: 11 )
• FROMMH ( type: esriFieldTypeString, alias: From Feature, length: 11 )
• DRAINAREA ( type: esriFieldTypeString, alias: Drainage Area, length: 255 )
• STREET ( type: esriFieldTypeString, alias: Street, length: 255 )
• SEWERCAT ( type: esriFieldTypeString, alias: Sewer Category, length: 255 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 20 , Coded Values: [Proposed: Proposed] , [Inactive: Inactive] , [Active: Active] , ...5 more... )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 500 )
• RETIRE_DATE ( type: esriFieldTypeDate, alias: RETIRE_DATE, length: 8 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
