Parent Layer: Storm Sewer

Name: Storm Gravity Main

Display Field: FACILITYID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Linear feature of stormwater gravity mains are line assets that derive most of the stormwater network. These mains are not pressurized, as those assets are stored in the swPressurePipe layer.

Service Item Id: 8a110ac22f8043cc89c4389fa1461b59

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.9221583803386834E7
YMin: -6279549.163759185
XMax: -1.1677358361923914E7
YMax: 6144906.458282975
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: OWNEDBY
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [255, 190, 232, 255]
Width: 1
Default Label: Others
UniqueValueInfos:
• Value: 1
  Label: City of Littleton
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [169, 0, 230, 255]
  Width: 1
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FACILITYID ( type: esriFieldTypeString, alias: Facility Identifier, length: 20 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• MATERIAL ( type: esriFieldTypeString, alias: Material, length: 20 , Coded Values: [ABS: ABS Plastic] , [AC: Asbestos Cement] , [ASP: Asphalt] , ...35 more... )
• WIDTH ( type: esriFieldTypeDouble, alias: WIDTH )
• MAINSHAPE ( type: esriFieldTypeString, alias: Main Shape, length: 50 , Coded Values: [Circular: Circular] , [Horseshoe: Horseshoe] , [Oblong: Oblong] , ...5 more... )
• PIPETYPE ( type: esriFieldTypeString, alias: Pipe Type, length: 50 )
• LINEDYEAR ( type: esriFieldTypeString, alias: Year Lined, length: 4 )
• LINERTYPE ( type: esriFieldTypeString, alias: Liner Type, length: 20 , Coded Values: [FF: Fold and Form or Deform/Reform] , [NONE: None] , [OTH: Other] , ...9 more... )
• DOWNELEV ( type: esriFieldTypeDouble, alias: Downstream Elevation )
• UPELEV ( type: esriFieldTypeDouble, alias: Upstream Elevation )
• SLOPE ( type: esriFieldTypeDouble, alias: Slope )
• FROMMH ( type: esriFieldTypeString, alias: From Manhole, length: 11 )
• TOMH ( type: esriFieldTypeString, alias: To Manhole, length: 11 )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• ACTIVEFLAG ( type: esriFieldTypeSmallInteger, alias: Active Flag , Coded Values: [0: False] , [1: True] )
• OWNEDBY ( type: esriFieldTypeSmallInteger, alias: Owned By , Coded Values: [4: Centennial Downs Metropolitan District] , [5: Cherry Hills Heights] , [6: Cherry Hills Village] , ...28 more... )
• MAINTBY ( type: esriFieldTypeSmallInteger, alias: Managed By , Coded Values: [4: Centennial Downs Metropolitan District] , [5: Cherry Hills Heights] , [6: Cherry Hills Village] , ...28 more... )
• SUMFLOW ( type: esriFieldTypeDouble, alias: Flow Summary )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHEETREF ( type: esriFieldTypeString, alias: Sheet Ref, length: 50 )
• LOCDESC ( type: esriFieldTypeString, alias: Location Description, length: 200 )
• GPSDATE ( type: esriFieldTypeDate, alias: GPS Date, length: 8 )
• DRAINAREA ( type: esriFieldTypeString, alias: Drainage Area, length: 255 )
• STREET ( type: esriFieldTypeString, alias: Street, length: 255 )
• SEWERCAT ( type: esriFieldTypeString, alias: Sewer Category, length: 255 )
• HEIGHT ( type: esriFieldTypeDouble, alias: HEIGHT )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• TracerWire ( type: esriFieldTypeSmallInteger, alias: Tracer Wire , Coded Values: [0: No] , [1: Yes] )
• LINEAR_FT ( type: esriFieldTypeDouble, alias: Linear Feet )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 20 , Coded Values: [Proposed: Proposed] , [Inactive: Inactive] , [Active: Active] , ...5 more... )
• LINERMATERIAL ( type: esriFieldTypeString, alias: LINERMATERIAL, length: 50 , Coded Values: [Bitumastic: Bitumastic] , [Cementitious: Cementitious] , [Epoxy: Epoxy] , ...7 more... )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 500 )
• RETIRE_DATE ( type: esriFieldTypeDate, alias: RETIRE_DATE, length: 8 )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
